Fusion 30

Black color is the 2024

The Fusion is the perfect blend of efficiency, capability, and reliability on the trail. The Fusion’s responsive handling characteristics and comfortable geometry will help you mix up your ride from the pathway, to the trail, and onto the singletrack. The Fusion’s geometry has been optimized to provide you with the best possible experience when heading out for a ride. We’ve updated the geometry to reflect the needs of a true ”downcountry” rider, including 29” wheels, a low standover height, longer reach, and a slacker head tube angle. With features like 100 mm of front travel, internal cable routing, and a 1x drivetrain, the Fusion sits at the top as our best all-around hardtail.

  • Frame
    Rocky Mountain 6061 Alloy | Threaded BB | Zero Stack Tapered Headtube Rear Triangle
  • Fork
    Suntour XCR32 LOR Air 100mm
  • Front Travel
  • Stem
    Rocky Mountain 31.8 XC | 7° Rise | All Sizes = 50mm
  • Handlebar
    Rocky Mountain XC | 760mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
  • Grips
    Rocky Mountain Lock On Light
  • Brakes
    Shimano MT4100 2 Piston | Resin Pads | F:Shimano RT10 160mm | R:Shimano RT10 160mm
  • Shifters
    MicroShift Advent X 10spd
  • Rear Derailleur
    MicroShift Advent X 10spd With Clutch
  • Cranks & Chainring
    Rocky Mountain Microdrive 2PC | 30T |76mm Asymmetrical BCD | 24mm Spindle | Crank Length: XS-SM-MD = 170-mm | LG - XL = 175mm
  • Bottom Bracket
    Rocky Mountain Sealed - Shimano Compatible
  • Cassette
    Shimano Deore 11-46T 10spd
  • Chain
    KMC X10-1
  • Front Hub
    Shimano TX505
  • Rear Hub
    Shimano TX505
  • Spokes
    2.0 Stainless
  • Rims
    Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape / Valves / Sealant Not Incl
  • Tires
    F: WTB Ranger Comp 29 x 2.4 // R: WTB Ranger Comp 29 x 2.4
  • Seatpost
    Rocky Mountain 30.9mm
