Rift Zone 1

This is the 27.5" wheel version, there is a 29" wheel version of this bike if you have long legs and the need for speed!

This bike is also known as the Hawk Hill It rips.

ALL AROUND TRAIL ENJOYMENT

The Rift Zone/Hawk hill is Marins most playful trail bike, made for the rider
that catches a bit of air off of every root in the trail, is always
looking for an alternate line, and ends every ride with a smile.
This is an all-around suspension bike with trail performance far
out stretching the asking price.

 Frame

Series 3 6061 Aluminum Frame, 27.5” Wheels, 120mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs

Front Suspension

RockShox Recon RL 27.5", 130mm Travel, Solo Air, Compression and Rebound Adjustment, Alloy Tapered Steerer, Fast Black Uppers, 110x15mm Boost Spacing, Maxle Stealth, 46mm Offset

Rear Suspension

X-Fusion O2 Pro R, Custom Tune, 210x50mm, 25mm x M8 Hardware Top and Bottom

Rim

Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible

Hub Rear

Forged Alloy, 141x9mm, Quad Sealed Bearings, 6-Bolt Disc, 32H, Standard Freehub Body

Hub Front

Forged Alloy, 110x15mm, 6-Bolt Disc, 32H

Spokes

14g Black Stainless Steel

Tires

Vee Tire, Crown Gem 27.5x2.3", Dual Control Compound, Folding Bead

Derailleur Rear

Shimano Deore Shadow Plus Direct Mount 10-Speed

Shift Lever

Shimano Deore 1x10-Speed

Crankset

Marin Forged Alloy 1x10, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD

Bottom Bracket

External Sealed Cartridge Bearings

Chain

KMC X10

Cassette

SunRace 10-Speed, 11-46T

Brakes Front

Shimano BR-MT201 Hydraulic Disc, 180mm Rotor

Brakes Rear

Shimano BR-MT201 Hydraulic Disc, 160mm Rotor

Brake Levers

Shimano BR-MT201 Hydraulic Disc

Handlebar

Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm rise, 5º Up, 9º Back

Stem

Marin 3D Forged Alloy, 35mm

Grips

Marin MTN, Closed End

Headset

FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

Seatpost

Marin Alloy, 30.9mm

Saddle

Marin Speed Concept

Pedals

-

Extras

Closed 9-12 Thru Axle QR System
